Rust: The Enemy of Your Welded Wire Fence

• air
• moisture
• abrasion

These three can make short work of breaking down iron and its common alloy--steel.

However, a coating of zinc reacts differently to these factors. As it corrodes, it forms a barrier (or patina), running interference between it and the steel or iron that it is sheltering.

Classes of Zinc Coating

Class 1--lightest coating of zinc; widely available and lasts 2 to 11 years in non-coastal climates. (.28% zinc per sq. foot)

• Protection drastically reduced in humid climates. (For the record, there is no Class 2.)

Class 3--heaviest coating of zinc; lasts 13 to 30 years, often must be special ordered (.80% zinc per sq. foot)

• However, in humid conditions, the coating may last at least 15 years with wider wire gauges lasting longer

Zinc galvanization creates a first-rate coating for mesh and fencing that lasts

After wires are either welded or woven into a mesh, the entire finished product is drawn through a bath of molten zinc (830°F.) This galvanization-after-weave or weld method (GAW) creates a mesh that emerges with a thick coating tightly bonded to the wire. Each strand of wire is protected and more importantly, each vulnerable welded or woven area is thoroughly sealed. In some circles, this is known as "galvanic healing!" Officially, this is termed, cathode-anode protection.

More zinc = more protection...

...delaying the time  until rust sets in. So the more zinc per square foot, the longer it is until it rusts.

What's at work here?  Friability.

If something is friable, it is subject to the rubbing process that works on the surface of unprotected iron or steel, which offers no natural corrosion-resistant patina. Friability describes the flaking and breaking apart of a solid substance.

And the benefits of a Class 3 zinc coating?

• Lowest cost over the long run
• Damage resistance--the zinc patina guards the metal underneath
• Cheaper than stainless steel
• Consistent results
• Longest life

And what does the ASTM standard actually mean?

Seeing this on a product, such as for zinc coatings, shows that a company is adhering to a certain set of criteria for the quality of a product. These are internationally accepted guidelines, based on research, for the specifications of materials, products, and services as approved by a  governing board. (ASTM International was once known as the American Society for Testing and Materials.) Buyer beware: a company's adherence to these standards is voluntary.

A Class 1 coating for your mesh or fence is anything but top rate. Now think again about that coating. It can mean: this looks fine or it'll do. In the long run (or even the short run), it will not stand up.

Various elements that cause deterioration:

           airborne sand and dust           chemicals             salt               air             pollution

A few zinc facts:

Zinc is the 27th most abundant element in the earth's crust. 70% is mined, 30% recycled. More than 50% of this is used to coat steel and keep it from disintegrating.

Zinc is found in rocks, soil, air, water, the biosphere as well as in humans, plants, and animals. (If you're an oyster lover, you're in luck: zinc is plentiful in oysters and it is essential for optimum health.)

Biology: organisms must have zinc to exist. For example, in the human body, zinc is important for cell division and is responsible for the function of red and white blood cells.

Finally, a short video:

Here's an example of zinc galvanizing in action:

Protecting people from lava flows and from themselves.

There are some fencing products on their way to Hawaii. It seems some physical barriers are required to offset the lava-play aficionados and looky-loos that are putting themselves at peril. For us at home, observing the mesmerizing lava flows from your screen of choice is a popular pastime, quite understandably. However, far from these screens is the tough job of predicting the actions of people who are curious or foolhardy enough to want to get close to the volcanic activity. Louis Page has been called in to assist with the fence and mesh needed to curb these adventurous and possibly harebrained scofflaws. Remember that vinyl coated high tensile wire is the fence of choice for longevity and strength.

Over-reacting? Nope.

The dangers are numerous:

• Those fascinating sea water explosions of boiling water and steam require onlookers to be at least a 1/4 of a mile away for safety. That steam is not just water vapor!
• Methane gas is created when vegetation is inundated without oxygen, exploding up to 100 yards ahead of the lava flow.
• The flows emit fumes that contain glass particles, sulfuric acid, and hydrochloric acid--no walking or standing in these toxic clouds.
• And some folks are enticed onto the new land created by the lava hitting the ocean--called benches--which are very unstable and prone to collapse.

Tourists and Hawaiian residents, observing bursts of gas and flame from the streams of lava, are being arrested for walking on hardened igneous rock and trespassing citations are handed out as people avoid barricades to take pictures, being caught going through areas with toxic gases.

The Phenomenon of Pele's Hair

And if the above list wasn't enough, there are the fine flaxen tresses of Pele. Named for the Hawaiian goddess of volcanoes, droplets of cooling lava are stretched up to six feet in the wind and should not be touched as it is actually volcanic fiberglass that can be very sharp and penetrate the skin. Here is a quick video to illustrate this phenomenon:

Fines

Entering certain zones bring a $5000 penalty and a year in jail. These reflect fines and punishments increased recently by the Department of Land and Natural Resources.

Is there a type of fence that you need to manage or direct pedestrians? Louis Page can assist you in finding just the right fence for your situation.

Essentials and Variables

Bekaert offers a fine variety of staples for attaching wire to wooden posts. Be it knurled or single and double barbed fence staples, Louis Page will make sure you've got the goods for your various projects.

To avoid harming the fence, there are some variables to keep in mind: A smooth wire electric fence requires loose-stapling each wire, while maintaining the consistency of the spaces by using a measuring stick with the spaces marked on it. Begin by stapling from the bottom.

For a barbed wire fence, again, loose stapling is required for each wire. Mark the positions of the wire with a measuring stick. Some folks find it helpful by starting at the top when installing multiple strands of barbed wire, as to avoid the successive wire from becoming hung up.

When working with woven wire, it is always necessary to loose-staple the wire. As the wire is expanding and contracting due to temperature fluctuations, freedom of movement under the staple is required for the brace to absorb the pressure, rather than the stapled post.

Now, here's a quick overview from Bekaert:
